Asus PRO Q570M-C/CSM mATX Mainboard

$174.00

FORM FACTOR: Micro-ATX
SOCKET TYPE: LGA 1200

Tags: ,
Model PRO Q570M-C/CSM
Supported CPU
CPU Socket Type  LGA 1200
CPU Type Supports 11th / 10th Gen Intel Core Processors
Supports Intel Pentium Gold and Celeron Processors* Refer to www.asus.com for CPU support list.
Supported CPU Technologies Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0*

* Intel Turbo Boost Max Technology 3.0 support depends on the CPU types.

Chipset  Intel Q570
Onboard Video
Onboard Video Chipset  Supported only by CPU with integrated graphic
Memory
Number of Memory Slots 4x288pin (DDR4)
Memory Standard DDR4 3200(OC) / 2933 / 2800 / 2666 / 2400 / 2133*

* 11th Gen Intel processors support 2933 / 2800 / 2666 / 2400 / 2133 natively.
* 10th Gen Intel Core i9 / i7 processors support 2933 / 2800 / 2666 / 2400 / 2133 natively, others will run at the maximum transfer rate of DDR4 2666.
* Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).
Maximum Memory Supported 128GB
Channel Supported  Dual Channel
Expansion Slots
PCI Express 4.0 x16 1 x PCI Express 4.0 x16*

* Actual support may vary by CPU.
PCI Express x1 2 x PCIe 3.0 x1
Other Slots M.2 slot only (Key E, CNVi & PCIe)*

* Wi-Fi module is sold separately.
Storage Devices
SATA 6Gb/s  6 x SATA 6Gb/s
M.2 Intel 11th & 10th Gen Processors:
M.2_1 slot (Key M), type 2242/2260/2280
- Only Intel 11th Core processors support PCIe 4.0 x4 mode, this slot will be disabled for other CPUsIntel Q570 Chipset:
M.2_2 slot (Key M), type 2242/2260/2280 (supports PCIe 3.0 x4 & SATA modes)*

* When a device in SATA mode is installed on the M.2_2 socket, SATA6G_2 port cannot be used.
* RAID function for PCIe mode SSD in Intel Rapid Storage Technology is available with either 1. Intel SSDs installed in both CPU-attached and PCH-attached slots, or 2. any other 3rd party SSDs installed in PCH-attached slots.
* To enable Intel Optane Memory (Hybrid Storage device), it must be installed in PCH-attached slots with Intel Rapid Storage Technology.
Intel Optane Ready Yes
Onboard Audio
Audio Chipset  Realtek ALC897
Audio Channels  7.1 Channels*

* A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output.
Onboard LAN
LAN Chipset Intel I219-LM
Max LAN Speed 10/100/1000Mbps
Rear Panel Ports
Back I/O Ports 4 x USB 3.2 Gen 2 ports (4 x Type-A)
2 x USB 2.0 ports (2 x Type-A)
2 x DisplayPort
1 x HDMI
3 x Audio jacks
1 x Intel I219-LM 1Gb Ethernet
1 x PS/2 keyboard (purple) port
1 x PS/2 mouse (green) port
Internal I/O Connectors
Onboard USB 1 x USB 3.2 Gen 1 Front Panel connector (suppports USB Type-C)
1 x USB 3.2 Gen 1 header supports additional 2 USB 3.2 Gen 1 ports
2 x USB 2.0 headers support additional 4 USB 2.0 ports
Other Connectors Fan and cooling related
1 x 4-pin CPU Fan header
2 x 4-pin Chassis Fan headers
Miscellaneous
1 x Clear CMOS header
1 x Chassis Intrude header
2 x COM Port headers
1 x Front Panel Audio header (AAFP)
1 x COM debug header
1 x DIS ME jumper
1 x LPT header
1 x Mono-out header (with Amp IC)
1 x M.2 slot (Key E)
1 x SMBUS header
1 x Speaker header
1 x 10-1 System Panel header
Physical Spec
Form Factor Micro ATX
Dimensions (W x L) 9.6" x 9.6"
Power Pin 1 x 24-pin Main Power connector
1 x 8-pin +12V Power connector
Features
Features Special Features:
ASUS EZ DIY
- Box Headers
Bespoke Motherboard Design & Business Focused Features
- ASUS Self Recovering BIOS
- ASUS Event Log
- ASUS Commercial BIOS kit
- Anti-Moisture
- 24/7 Reliability
- Overcurrent Protection
TPM 2.0 IC onboardSoftware Features:
ASUS Exclusive Software
IT Management software supported
- ASUS Control Center Express (ACCE)

BIOS:
128+64 MB Flash ROM

Manageability:
WOL by PME, PXE

Operating System:
Windows 10 - 64-bit
Packaging
Package Contents Accessories:
Cables
2 x SATA 6Gb/s cables
Miscellaneous
1 x I/O Shield
1 x M.2 SSD screw package
1 x M.2 Key E screw package
Installation Media
1 x Support DVD
Documentation
1 x ACC Express Activation Key Card
1 x User manual
